Flo CoRe+ Max - Pedestal Specifications; Pedestal

7
3. Pedestal Specifications
The pedestal is designed to be installed using these components: the pedestal enclosure, a cascading kit (on
certain pedestal models), and a pedestal anchor. An optional cable management system is also available.
3.1. Pedestal
The pedestal has an access door latch that can be secured using a padlock (not included).
3.1.1. Specifications
The table below displays the pedestal specifications:
Product family CoRe+ MAX
Model ACPE000022
Ingress protection rating 3R enclosure type; suitable for outdoor use
Shipping weight Approximately 25 lbs. not including packaging
Security standard
compliance
UL 50E / CSA C22.2 No. 94.2
Enclosures for Electric Equipment, Environmental
Considerations
Specification information sticker
Charging station back plate
Latch
Access door screws
Access door
Safety warning sticker
Ground terminal
Ground sticker
