Flott TB 10 Plus - Page 4

Contents
4 14/03/2023 212601
3 Technical Description 25
3.1 Functional Description .......................................................................................... 25
3.2 Machine Overview ................................................................................................ 26
4 Installation of the Machine 27
5 Before Using the Machine 29
5.1 Mounting Accessories and Options ....................................................................... 29
5.1.1 Mount Drill Chuck .................................................................................. 29
5.1.2 Installing the Cutter ............................................................................... 30
5.1.3 Set Drill Guard and Press ..................................................................... 31
5.1.4 Installing Machine Vice ......................................................................... 32
5.2 Adjusting the Height of the Machine ..................................................................... 33
5.2.1 Adjust Turbo Drill and TB 10 Plus in height ........................................... 33
5.2.2 Adjusting SB 13/15 Plus, TB 13/15 Plus and TBZ 13/15 Plus in height . 33
5.3 Connecting the Machine Electrically ..................................................................... 34
5.4 Checks Before Commissioning ............................................................................. 35
6 Operating the Machine 36
6.1 Control Elements of the Machine .......................................................................... 36
6.2 Drilling Through Hole ............................................................................................ 39
6.3 Drilling Hole with Limiter ....................................................................................... 41
6.4 Bore with Depth Adjustment ................................................................................. 43
6.5 Tapping with Depth Adjustment ............................................................................ 46
6.6 Changing Drilling Parameters ............................................................................... 49
6.7 Calling up the Operator Menu of the Control System ........................................... 51
