Operating the Machine
48
14/03/2023 212601
Note
Slightly correct the position of the spindle with the drill lever when cutting a
thread. This will relieve the tensile force on the thread. This is especially im-
portant for soft materials.
11. Use the drill lever to slowly move the tap towards the workpiece by press-
ing down on the drill lever.
Cut the thread into the pre-drilled hole of the workpiece.
As soon as the pre-set threading depth is reached, the direction of rotation
of the spindle automatically switches to counter clockwise rotation and the
tap is moved out of the cut thread.
12. Then return the drill lever back to its initial position.
As soon as the tap is moved out of the workpiece (displayed drilling depth
-0.3 mm), the direction of rotation of the spindle changes back to a clock-
wise direction.
13. Press the push-button to stop the machine.
The lamp lights up when the drive is off.
The machining operation is over.
