Operating the Machine
50
14/03/2023 212601
Setting spindle stop
In the control system you can basically set whether the spindle
Remains permanently on after the machine start (until the machine stops)
or
Is switched off automatically after the drilling operation and reaching the
upper spindle position. This can for example be useful for safety reasons.
In the basic setting, the spindle stop is switched off and can be set accordingly
in the operator menus. Please see section 6.7 Calling up the operator menu of
the control system on page 51.
Setting piece counter
The control system is equipped with a piece counter. The piece counter counts
the number of holes only when the machine is running. It always starts after
the start of the machine with the number 0. As soon as the pre-set drilling
depth is reached during a drilling operation, the piece counter is incremental
by 1.
Note
As soon as the piece counter is reset to 0, the zero point is also reset. There-
fore, check the zero point for further holes and adjust it if necessary.
With the machine stopped, press the push-button for at least 3 seconds to
set the piece counter to 0. This will reset the zero point, which then has to
be readjusted if necessary.
