REGULATION INSTRUCTIONS
50
PARAMETER P20 – CENTRAL HEATING MAXIMUM SET POINT
This parameter is used to set the central heating maximum user set point.
To enter the parameters menu, follow the previously described procedure
(see paragraph 5.2 ‘Accessing the parameters menu’ - steps 1-4).
5. Use
and buttons (D.H.W temperature setting) to modify the
value of the parameter within the prescribed limits (displayed in Celsius
degrees):
min = 40 °C
max = 88 °C
6. Press mode selection button
to confirm and to render the new
parameter operative.
7. To exit from the parameters menu, press simultaneously
and
buttons.
PARAMETER P21 – D.H.W. MAXIMUM SET POINT
This parameter is used to set the D.H.W maximum user set point.
To enter the parameters menu, follow the previously described procedure
(see paragraph 5.2 ‘Accessing the parameters menu’ - steps 1-4).
5. Use
and buttons (D.H.W temperature setting) to modify the
value of the parameter within the prescribed limits (displayed in Celsius
degrees):
min = 45 °C
max = 75 °C
6. Press mode selection button
to confirm and to render the new
parameter operative.
7. To exit from the parameters menu, press simultaneously
and
buttons.
PARAMETER P22 – ΔT SET POINT T° FLOW/ T° RETURN
(w/modulating pump and return temperature sensor connected only)
To enter the parameters menu, follow the previously described procedure
(see paragraph 5.2 ‘Accessing the parameters menu’ - steps 1-4).
5. Use
and buttons (D.H.W temperature setting) to modify the
value of the parameter within the prescribed limits (displayed in Celsius
degrees):
Disable = 00 (must be set to 00)
min = 10 °C
max = 40 °C
6. Press mode selection button
to confirm and to render the new
parameter operative.
7. To exit from the parameters menu, press simultaneously
and
buttons.
