EP5 Electro Pneumatic Digital Positioner FCD PMENIM0006-00-A5 12/18
25
P5 EP5
Input Signal 20-100 kPa/3-15 Psi (6-30 optional) 4-20 mA
Linearity ≤ 0,5%* ≤ 0,5%*
Hysteresis ≤ 0,75%* ≤ 0,5%*
Repeatability ≤ 0,5%* ≤ 0,5%*
Gain (pressure 600 kPa/87 Psi)
1 000 (kPa/kPa)
Min 66%/% ISA S75.13
Air consumption at Supply pressure:
0,2 MPa/29 Psi 5,4 nl/min 0.19 SCFM 6,1 nl/min 0.22 SCFM
0,4 MPa/58 Psi 12,3 nl/min 0.43 SCFM 13,6 nl/min 0.48 SCFM
0,6 MPa/87 Psi 20 nl/min 0.71 SCFM 22 nl/min 0.78 SCFM
0,8 MPa/116 Psi 27,8 nl/min 0.98 SCFM 30,5 nl/min 1.08 SCFM
1 MPa/145 Psi 35,7 nl/min 1.26 SCFM 39 nl/min 1.38 SCFM
Air delivery at Supply Pressure:
0,2 MPa/29 Psi 200 nl/min 6.9 SCFM 200 nl/min 6.9 SCFM
0,4 MPa/58 Psi 370 nl/min 12.8 SCFM 370 nl/min 12.8 SCFM
0,6 MPa/87 Psi 540 nl/min 18.8 SCFM 540 nl/min 18.8 SCFM
0,8 MPa/116 Psi 710 nl/min 24.7 SCFM 710 nl/min 24.7 SCFM
1 MPa/145 Psi 880 nl/min 30.6 SCFM 880 nl/min 30.6 SCFM
Supply Pressure Max 1 MPa/150 Psi 0,15-1 MPa/21,8-150 Psi
Temperature range -20°C to -85°C (-4°F to 185°F) -20°C to -85°C (-4°F to 185°F)
Connector threads ¼” NPT or G ¼” NPT or G
Gauge threads 1/8” NPT or G 1/8” NPT or G
Weight std. 1,1 kg/2.4 lbs 1,5 kg/3.4 lbs
Weight with gauges 1,3 kg/2.9 lbs 1,8 kg/3.9 lbs
Ingress protection IP 66/NEMA 4
* % of full scale.
(The information in this manual is subject to change without notice.)
