15. Technical data
P4
Input Signal 20-100 kPa/3-15 Psi (6-30 Psi optional)
Linearity (%)* 0,7
Hysteresis+deadband (%)* 0,8
Repeatability (%)* 0,5
Pressure gain at load 20% (%/%) 20 %/% ISA 75.13 1989
(kPa/kPa) 300
Air consumption at supply pressure:
0,6 MPa/87 Psi 8 nl/min (0.31 SCFM)
Air delivery at supply pressure:
0,2 MPa/29 Psi 140 nl/min (5.46 SCFM)
0,4 MPa/58 Psi 245 nl/min (9.55 SCFM)
0,6 MPa/87 Psi 350 nl/min (13.65) SCFM
Supply Pressure Max 1 MPa/150 Psi
Temperature range -20°C to +85°C (-4°F to 185°F)
Connector threads 1/4” NPT
Weight std. 0,9 kg/2 lbs
* % of full scale.
