Flowserve APEX 7000 User Manual

EP5 Electro Pneumatic Digital Positioner FCD PMENIM0006-00-A5 12/18
30
Pos Part no Qty Description
1 1 Housing
2 P5-2 1 Front Cover incl. O-ring
3 P5-AS3N 1 Connecting block NPT 1/4”assembly
3 P5-AS3G 1 Connecting block G 1/4” assembly
4 P5-4 1 Relief valve spring
6 P5-6P 1 Gasket for P5
6 P5-6EP 1 Gasket for EP5
7 P5-7 1 Diaphragm cover incl. O-ring
8 P5-8 1 Diaphragm
9 P5-9 2 Diaphragm washer
10 P5-1 1 Balance arm
13 P5-AS13/315 1 Feedback spring 3-15 psi assembly
13 P5-AS13/630 1 Feedback spring 6-30 psi assembly
18 P5-18 1 Lower arm assembly
19 P5-19 1 Rod
20 P5-20 1
Spring
21 P5-21A 1
Indicator Arrow
21 P5-21F 1
Indicator Flag
21 P5-21P 1
Indicator Pointer
22 P5-22T 1
Indicator cover Transparent incl. O-ring
22 P5-22F 1 Indicator cover Flag incl. O-ring
22 P5-22B 1 Indicator cover Blind incl. O-ring
24 P5-24 1 Twist stop
25 P5-25 1 Pilot valve incl. O-rings
26 P5-26 1 Shaft incl. O-rings, screw
27 P5-27 1 Cam locking nut incl. screw
29 P5-29 1 Zero cover
30 P5-30 1 Cover
31 P5-31 1 Mounting adapter, incl screws
32 P5-32 1 Ball bearing
35 P5-xx/xx 1 Identification cover
36 12047N 4 Plug NPT 1/8”
36 12047G 4 Plug 1/8” G
37 P5-Kxx 1 Cam
38-45 P5-Screws 1 Screw set P5/EP5
75-80
46-53 P5-Seal NBR 1 O-ring set P5/EP5
81-83, 6, 67, 70 Nitrile, NBR
46-53 P5-Seal Q 1 O-ring set P5/EP5
81-83, 6, 67, 70
Silicone, Q
54 P5-Sxx 1 Spindle adaptor
