3
Actuator Weight
The following table is an L120-85 representative weight chart. It provides the weight of several components
that may be incorporated into a typical package. Use the chart as a guideline to estimate the weight of your
particular actuator package.
Table 1: L120-85 Approximate Weight Chart
Components lb. kg
L120-85 with 40 ft-lb 1700 RPM Motor (Torque only) 275 125
With Minimum Integral Control
Package and Compartment
315 143
Thrust Base Assembly (Drive 2)
1
70 32
1
Add to weights shown above for basic actuator or basic actuator with integral control package.
Limitorque L120-85 Installation, Operation and Maintenance FCD LMENIM1202-03-A4 – 06/15
8
