10.2 L120-85 Parts List
Piece Description Quantity
1 Unit Housing 1
2 Handwheel Shaft 1
2-1 Handwheel Shaft Key 1
3-1 Handwheel Lugs 1
3-2 Handwheel Shaft Spring 1
3-3 Handwheel Shaft Roll Pin 1
4-1 Handwheel Bushing 1
4-2 Handwheel Spacer 1
4-3 Handwheel Spacer Retaining Ring 1
5 Handwheel End Cap 1
6-1 Handwheel Shim 6
7-1 Declutch Link 1
7-2 Declutch Link Key 1
8 Declutch Return Spring 1
9 Declutch Lever Assembly 1
10 Declutch Lever Roll Pin 1
11 Declutch Lever Stop Plate 1
12 Declutch Lever Washer 1
14 Grounding Lug Kit 1
15-1 Worm Shaft* 1
15-2 Worm* 1
15-3 Worm Shaft Assy. Ball Bearing* 1
15-4 Worm Shaft Assy. Ball Bearing* 1
15-5-1 Worm Shaft Assy. Disc Spring* 12
15-5-2 Worm Shaft Assy. Spring Pack Shim* 12
15-6 Worm Shaft Assy. Disc Spring Spacer* 2
15-7 Worm Shaft Assy. Disc Spring Mandrel* 1
15-9 Worm Shaft Assy. Bearing Adapter* 1
15-10 Worm Shaft Assy. Flange Nut 1
15-11 Worm Shaft Assy. Key 1
15-12 Worm Shaft Assy. Retaining Ring 1
16 Drive Sleeve Ball Bearing 1
17 Drive Sleeve Top Bearing* 1
18-1 Clutch Pinion 1
18-2 Clutch Pinion Ball Bearing 1
Piece Description Quantity
18-3 Clutch Pinion Retaining Ring* (not shown) 1
19-1 Clutch 1
19-2 Clutch Assy. Ball Bearing 1
19-3 Clutch Assy. Retaining Ring 1
20 Handwheel Shaft Needle Bearing 1
21 Worm Gear 1
22 Retaining Ring 1
23 Thrust Bearing 1
24 Thrust Bearing Washer 2
25 Drive Sleeve 1
26 Bearing Backup Washer 1
27 Unit Base Plate 1
28 Needle Bearing 1
29-1 2" Square Nut Assembly* 1
29-2 Handwheel 1
30 Declutch Compression Spring* 1
31-1 Motor 1
31-2 Conduit Nipple 1
32-1 Clutch Latch 1
32-2 Clutch Latch 1
33 Latch Spring 1
34 Washer* 1
36 Key 1
37 Flanged Lock Nut 1
38 Motor Cam 1
39 Key (Motor) 1
40 Socket Head Set Screw 1
41 Retaining Ring 1
42-1 Quad Ring 1
42-2 O-ring 1
42-3 Motor Gasket 1
42-4 Handwheel End Cap Gasket 1
42-5 Quad Ring 1
42-6 O-ring 1
43 O-ring (not shown) 1
