Fluidwell F103 WP User Manual

Page 20
FW-F103-P-XN-M_v2002_03_EN.docx
3.3.4 EXPLANATION OF SETUP-MENU 3 - DISPLAY
3
DISPLAY
3.1
FUNCTION
This setting determines which information is shown on the main
screen. The function can be set to indicate total, flowrate or
accumulated total.
• When “total” is selected, total is displayed with the large 12mm
(0.47”) digits and flowrate is displayed with the 7 mm (0.28”) digits
simultaneously.
• When “flowrate” is selected, only flowrate will be displayed with
the large 12mm (0.47”) digits together with its measuring unit.
• When "accumulated total" is selected, total is displayed with the
large digits and accumulated total is displayed with the small
digits simultaneously.
When SELECT is pressed on the main screen, the operator can scroll
through the various process values. See chapter 2 for more
information on operator information and functions.
3.2
DAY TOTALS
A basic data log function is available to register Current Day Total and
Previous Day Total. This function sets the availability at operator
level:
• Off: Current Day Total and Previous Day Total are not available.
• Operator: Current Day Total and Previous Day Total are available
at operator level by pressing the SELECT key several times.
At SETUP-level, they can be reviewed at SETUP 1.7 and
SETUP 1.8.
• Hidden: Current Day Total and Previous Day Total are only
available at SETUP 1.7 and SETUP 1.8.
When this function is enabled, a list of the last 15 historical day totals
is available and can be reviewed from operator level.
Please see paragraph 2.3 for more information.
3.3
BACKLIGHT
The unit can be provided with a backlight (Type -ZB). The backlight
brightness can be adjusted from 0% (off) to 100% in steps of 20%.
The following can be selected:
0% - 20% - 40% - 60% - 80% - 100%
To use the backlight, the unit must be powered externally.
With battery power or loop power the backlight will not work.
3.3.5 EXPLANATION OF SETUP-MENU 4 – POWER MANAGEMENT
When battery powered, the user can expect reliable measurement over a long period of time. The
F103-P has several smart power management functions to extend the (optional) battery life time
significantly. The following settings are available:
4
POWERMAN
4.1
LCD NEW
The calculation of the display-information influences the power
consumption significantly. When the application does not require a
fast display refresh rate, it is strongly advised to select a slow refresh
rate. Please understand that NO information will be lost; every pulse
will be counted and output signals are generated in the normal way.
The following can be selected:
FAST – 1 sec – 3 sec – 15 sec – 30 sec – OFF
After a button has been pressed by the operator - the display refresh
rate will always switch to fast for 30 seconds.
When 'OFF' is selected, the display will temporarily turn on after
touching one of the keys and turn off automatically after 30 seconds.
4.2
BATTERY MODE
The F103-P has two modes: operational or shelf.
When "shelf" is selected, the F103-P shuts down and can be stored
for several years: it will not process the sensor signal and the display
is switched off but all settings and totals are stored.
In this mode, power consumption is extremely low.
To wake up the F103-P again, press the SELECT/▲-key two times.
