Fluke 1523 User Manual

1523, 1524 Reference Thermometer
Setup
10
Table 4 1523 Key Functions
No Key Description
1 Power on or off
2 Yellow Second or Special Function Key
3 Turns the backlight on or off
4
STATS
1st Press: MAX, 2nd Press: MIn, 3rd Press: AVE, 4th Press: STD DEV
5
°
C
°
F
Units, °C/°F
6
HOLD
1st press - Holds value on screen "-- HOLD --" across bottom of screen. 2nd press -
Releases Screen hold.
7
SETUP
Enters setup menu, see menu structure
8
SAVE
Saves measurement as a logged data point
9
Arrows increment or decrement selections in an active eld. In Graph Mode, Arrows change
the scale of the graph.
10
ENTER
Selects highlighted selection, Saves a new selection.
11
RECALL
1st Press - Enters Recall menu, 2nd Press - Exits Recall Menu
12
NEXT
Moves down to next option on screen.
13
+
STATS
“RESET” - Resets Stats Data
14
+
°
C
°
F
“Ω mV” - Toggles from °C to Ω or Ω to °C (PRT, thermistor), °C to mV or mV to °C (TC)
15
+
HOLD
“TREND” - Starts Graphing data
16
+
ENTER
“HOME” Returns user to main screen
