Fluke 1587 MDT User Manual

Insulation Multimeter
Rotary Switch Positions
7
Rotary Switch Positions
Turn the Meter on by selecting any measurement function.
The Meter presents a standard display for that function
(range, measurement units, modifiers, etc.). Use the blue
button to select any rotary switch alternate functions
(labelled with blue letters). Rotary switch selections are
shown and described in Table 4.
Table 4. Rotary Switch Selections
bav02f.eps
1587 FC 1587 1587T 1577
Switch
Position
Measurement Function
B
AC voltage from 30.0 mV to 1000 V.
• • • •
K
AC voltage with 800 Hz VFD low-pass filter.
• • •
C
DC voltage 1 mV to 1000 V.
• • • •
E
DC mV 0.1 mV to 600 mV.
• • • •
