Fluke 1630-2 User Manual

Earth Ground Clamp
Memory
19
Memory
You can log >2000 measurements in the Clamp memory.
View Memory
To view logged measurements in memory:
1. Push and hold  >2 s to go the view memory mode.
The most recent logged measurement shows on the
display with an ID#. See Figure 12.
Figure 12. Logged Measurements
2. Press  /  to go to the next or previous ID# (memory
location). The ID# rolls over when you reach the first or
last record.
3. Push  to toggle the display to show the time or date
for the logged measurement. See Figure 13.
Figure 13. Timestamp
Clear Memory
To clear the memory:
1. In measurement mode, simultaneously push and hold
 / .
2. Push  to confirm and finish the clear action.
The clamp automatically goes back to measurement
mode.

Fluke 1630-2 Specifications

General

Type	Earth Ground Clamp Meter
Ground Resistance Range	0.025 Ω to 1500 Ω
Display	LCD
Data Logging	Yes
Operating Temperature	-10 °C to 50 °C
Storage Temperature	-20 °C to 60 °C
Ground Resistance Accuracy	±(1.5% + 0.02 Ω)
Jaw Opening	32 mm
Power Supply	AA batteries
Safety Rating	CAT IV 600 V
