Logger/Monitor
Setup
11
Setup
Before you start the verification procedures or make calibration adjustments, refer to this section for the
equipment, system, and setup requirements.
Required Equipment
See Table 3 for a list of requirements for the verification tests and calibration adjustment of the Logger.
Table 3. Required Equipment
Equipment Model Notes
Used on:
Verification
Tests
Calibration
Adjustment
Calibrator 5522A 5520A is also supported
XX
Cable Assembly 3PHVL-1730
Voltage Test Lead
3-Phase+N
XX
173x AUX Input Calibration
Cable
[1]
NA
1732/1734/1736/1738 only
XX
173x Calibration Cables –
Voltage-to-Current Input Cable
Assembly
[1]
NA
1732/1734/3540 FC:
Qty. 3 required
1736/1738:
Qty. 4 required
XX
173x Verification Box
[1]
NA optional
X
USB cable type A-to-mini B
XX
DMM 8846A
for AUX Adapter
verification
X
Coil
5500A/COIL
Optional: 52120A
with Coils
for Flexi verification
X
Coil NA 5 turns
X
Banana-to-Pin Adapter
Pomona
Electronics 4690
for AUX Adapter
verification
X
[1] The 173x calibration cables and verification box are not available from Fluke. See Equipment Assembly for
information on how to make these items.
