1732/1734/1736/1738/3540 FC

Calibration Manual

Specifications

General Specifications

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.3-inch active matrix color TFT, 480 pixels x 272 pixels, resistive touch panel

Power/Charging/LED Indicator

Warranty

173x/3540 FC and Power Supply . . . . . . . . . . . . . . . . . . .2 years (battery not included)

Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 year

Calibration Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2 years

Dimensions

173x/3540 FC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19.8 cm x 16.7 cm x 5.5 cm (7.8 in x 6.6 in x 2.2 in)

Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13.0 cm x 13.0 cm x 4.5 cm (5.1 in x 5.1 in x 1.8 in)

173x/3540 FC with power supply attached . . . . . . . . . . . . 19.8 cm x 16.7 cm x 9 cm (7.8 in x 6.6 in x 4.0 in)

Weight

173x/3540 FC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.1 kg (2.5 lb)

Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .400 g (0.9 lb)

Tamper Protection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Kensington lock

Environmental Specifications

Operating Temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . -10 °C to +50 °C (14 °F to 122 °F)

Storage Temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -20 C to +60 °C (-4 °F to +140 °F),

with battery: -20 °C to +50 °C (-4 °F to +122 °F)

Operating Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <10 °C (<50 °F) non condensing

10 °C to 30 °C (50 °F to 86 °F) ≤95 %

30 °C to 40 °C (86 °F to 104 °F) ≤75 %

40 °C to 50 °C (104 °F to 122 °F) ≤45 %

Operating Altitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2000 m (up to 4000 m derate to 1000 V CAT II/600 V CAT III/300 V CAT IV)

Storage Altitude. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 000 m

IP Rating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IEC 60529:IP50, in connected condition with protection caps in place

Vibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . MIL-T-28800E, Type 3, Class III, Style B

Safety

General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IEC 61010-1: Pollution Degree 2

Measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IEC 61010-2-033: CAT IV 600 V / CAT III 1000 V

Mains Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Overvoltage Category II, Pollution Degree 2

Voltage Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Overvoltage Category IV, Pollution Degree 2

Li-ion Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IEC 62133

Electromagnetic Compatibility (EMC)

International. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . IEC 61326-1: Industrial

CISPR 11: Group 1, Class A

Group 1: Equipment has intentionally generated and/or uses conductively-

coupled radio frequency energy that is necessary for the internal function of the

equipment itself.

Class A: Equipment is suitable for use in all establishments other than domestic

and those directly connected to a low-voltage power supply network that

supplies buildings used for domestic purposes. There may be potential

difficulties in ensuring electromagnetic compatibility in other environments due to

conducted and radiated disturbances.

Emissions that exceed the levels required by CISPR 11 can occur when the

equipment is connected to a test object.

Korea (KCC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Class A Equipment (Industrial Broadcasting & Communication Equipment)

Class A: Equipment meets requirements for industrial electromagnetic wave

equipment and the seller or user should take notice of it. This equipment is

intended for use in business environments and not to be used in homes.

USA (FCC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 CFR 15 subpart B. This product is considered an exempt device per clause

15.103.
