Logger/Monitor
Setup
19
Calibration and Verification
The Calibration and Verification sheet are the built-in procedures. See Table 9.
Table 9. Calibration and Verification in Excel Worksheet
Item Description
hcf102.eps
hcf103.eps
Start button – When the selection window has been closed with Quit, click the Start button again to
open.
Selection window – Click on Verification, Calibration, and Setup to select the action. Close the window with
Quit. Open again with Start .
Verification items – Select Voltage Input, AUX Input or Current Input to verify. For a Logger verification, all
three items must be verified sequentially. Make sure the sensor selector is set to DIRECT for the
Logger verification. A specific order is not required.
Verification Calibration Setup
3 5 6 74
