Logger/Monitor
Optional Verification for Flexi or Clamp (Combined Logger and Probe Specifications)
25
Table 14. Clamp Current Probe Input Verification with 52120A Coil
7. When you are done, set the calibrator to Standby.
Type/Range
52120A Range
5520A
Voltage
Applied
Signal
Upper
Limit
Lower
Limit
i40S-EL, Clamp 40A HIGH 2 A 0.4 V 0.4 A 0.4108 0.3892
i40S-EL, Clamp 40A HIGH 20 A 0.4 V 4 A 4.036 3.964
i40S-EL, Clamp 40A HIGH 120 A 0.4 V 40 A 40.288 39.712
i40S-EL, Clamp 40A LOW 2 A 0.04 V 0.04 A 0.04108 0.03892
i40S-EL, Clamp 40A LOW 2 A 0.4 V 0.4 A 0.4036 0.3964
i40S-EL, Clamp 40A LOW 20 A 0.4 V 4 A 4.0288 3.9712
iFlex1500-12, Flexi 1500A HIGH 120 A + 3 KA COIL
[1]
0.6 V 1500 A 1515.3 1484.7
iFlex1500-12, Flexi 1500A HIGH 120 A + 3 KA COIL
[1]
0.32 V 800 A 808.3 791.7
iFlex1500-12, Flexi 1500A HIGH 120 A 1 V 100 A 101.3 98.7
iFlex1500-12, Flexi 1500A LOW 120 A 1.1 V 110 A 111.1 108.9
iFlex1500-12, Flexi 1500A LOW 120 A 0.6 V 60 A 60.6 59.4
iFlex1500-12, Flexi 1500A LOW 2 A 1 V 1 A 1.04 0.96
iFlex3000-24, Flexi 3000A HIGH 120 A + 3 KA COIL
[1]
1 V 2500 A 2525.9 2474.1
iFlex3000-24, Flexi 3000A HIGH 120 A + 3 KA COIL
[1]
0.48 V 1200 A 1212.9 1187.1
iFlex3000-24, Flexi 3000A HIGH 120 A 1 V 110 A 112.0 108.0
iFlex3000-24, Flexi 3000A LOW 120 A + 3 KA COIL
[1]
0.1 V 250 A 252.6 247.4
iFlex3000-24, Flexi 3000A LOW 120 A 1.1 V 110 A 111.2 108.8
iFlex3000-24, Flexi 3000A LOW 2 A 1 V 1 A 1.07 0.93
iFlex6000-36, Flexi 6000A HIGH 120 A + 6 KA COIL
[1]
1.1 V 5500 A 5584.3 5415.7
iFlex6000-36, Flexi 6000A HIGH 120 A + 6 KA COIL
[1]
0.5 V 2500 A 2539.3 2460.7
iFlex6000-36, Flexi 6000A HIGH 120 A 1 V 100 A 103.3 96.7
iFlex6000-36, Flexi 6000A LOW 120 A + 6 KA COIL
[1]
0.11 V 550 A 558.4 541.6
iFlex6000-36, Flexi 6000A LOW 120 A 1.1 V 110 A 111.8 108.2
iFlex6000-36, Flexi 6000A LOW 2 A 1 V 1 A 1.20 0.80
[1] Steps that use coils are for performance check only due to the low TUR (Test Uncertainty Ratio).
