Digital Multimeters
Detailed Specifications
47
28 II AC Voltage
AC conversions are ac-coupled and valid from 3 % to 100 % of range.
Accuracy
Range Resolution
45 – 65 Hz 15 – 200 Hz 200 – 440 Hz 440 Hz – 1 kHz 1 – 5 kHz 5 – 20 kHz
600.0 mV 0.1 mV
6.000 V 0.001 V
±(0.7 % + 4) ±(2 % + 4)
±(2 % + 20)
[2]
60.00 V 0.01 V Unspecified
600.0 V 0.1 V
±(2 % + 4)
[3]
Unspecified
1000 V 1 V
±(1.0 % + 4)
[1]
Unspecified Unspecified
Low-Pass Filter
±(0.7 % + 2)
±(1.0 % + 4)
[1]
+1.0 % + 4
-6.0 % - 4
[4]
Unspecified Unspecified Unspecified
[1] Below 30 Hz, use smoothing function.
[2] Below 10 % of range, add 12 counts.
[3] Frequency range: 1 to 2.5 kHz
[4] Specification increases from -1 % to -6 % at 440 Hz when filter is used.
