Fluke 6500 - Test parameters; Setting Manual Test Limits

Fluke 6500
Users Manual
12
Table 2. Test parameters
Test Parameter
Visual check (Skipped) - SELECTED
Bond
Current
Repeat
1)
Limit
Duration
200mA – 25A
R0 – R1 – R2 - R3
0.1 …19.9
(Skipped) - 5s….60s
Insulation
Repeat
Safety Class
2)
Limit
Duration
R0 – R1 – R2 - R3
I – II
0.1 M…290M
(Skipped) - 5s….60s
Substitute Leakage
Limit
Safety Class
2)
Duration
0.5mA … 19.5mA
I – II
(Skipped) - 5s….60s
Load/leakage
Limit Load
Limit Leakage
Duration
0VA…3200VA
0.5mA …19.5mA
(Skipped) - 5s….60s
Touch Current
Repeat
Limit
Duration
R0 – R1 – R2 - R3
0.25mA, 0.5mA – 1.9mA
(Skipped) - 5s….60s
IEC Lead
Limit Rpe
Duration
3)
Limit Riso
0.1…19.9
(Skipped) - 5s….60s
fixed at 2 M
Notes:
1) The repeat test parameters R0, R1, R2, and R3
define how many times a test will be repeated.
When you select for example R1, the test will be
repeated once (two tests).
2) The selected class for the isolation test also
applies to the substitute leakage test.
3) The IEC lead test can only be selected if all
other tests, except for the visual check, are
skipped.
Setting Manual Test Limits
To set the manual test limits you need your access code
(factory default 9999).
Do the following:
1
SET
UP
Open the set-up menu.
2 Highlight MANUAL LIMITS
3
GO
Open the next menu and follow the screen
instructions.
To restore the factory set limits press
NO
.
For the test parameters see Table 2.
