Users Manual
Specifications
37
Resolution ..................................... 0.01 M (0 to 9.99 M)
0.1 M (10 to 99.9 M)
1 M (100 to 299 M)
Test Voltage ............. 500 V dc –0 % +25 % at 500 k load
Test Current ........... >1 mA at 500 k load, < 15 mA at 0
Auto discharge time.....................................< 0.5 s for 1 μF
Max. Capacitive Load.......................operational up to 1 μF
Substitute Leakage Current Test
Operational Error Measurement Range ...0.25 to 19.00 mA
Operational Error..........................................................10%
Accuracy .................................................± (5% + 5 counts)
Display Range..........................................0 to 19.99 mA ac
Resolution ............................................................. 0.01 mA
Test Voltage .................................................35 V ac ± 20%
(at nominal mains input voltage)
Touch Current Test
Operational error Measurement Range...0.1 to 1.99 mA ac
Operational error .........................................................6.0%
Accuracy .................................................± (4% + 2 counts)
Display Range............................................0 to 1.99 mA ac
Resolution ............................................................. 0.01 mA
Internal Resistance (via probe).................................... 2 k
Measuring method..................................................... Probe
The appliance under test is energized at mains potential.
Load/Leakage Test: Load Current
Display Range...................................................... 0 to 13 A
Accuracy .................................................± (4% + 2 counts)
Resolution .................................................................. 0.1 A
The appliance under test is energized at mains potential.
Load/Leakage Test: Load Power
Display Range.................................................. 0 to 999 VA
1.0 kVA to 3.2 kVA
Accuracy .................................................± (5% + 3 counts)
