Fluke 6500 - Page 24

Fluke 6500
Users Manual
18
Table 3. Factory Programmed Auto-Tests for Class I Appliances
Tests 131 132 133 134 135 136
Visual Inspection Yes Yes Yes Yes Yes Yes
Earth Bond 25A () 0.10 0.10 No No 0.10 No
Earth Bond 200mA No No 0.10 0.10 No 0.10
Insulation (M) 1.00 1.00 1.00 1.00 1.00 1.00
Touch Current (mA) No No No No No No
Substitute Leakage (mA) No No No No No No
Load/Leakage (VA/mA) 3000/3.5 3000/0.75 3000/3.5 3000/0.75 No No
Table 4. Factory Programmed Auto-Tests for Class II Appliances
Tests 231 232 233 234
Visual Inspection Yes Yes Yes Yes
Earth Bond 25A () No No No No
Earth Bond 200mA No No No No
Insulation (M) 2.00 2.00 2.00 2.00
Touch Current (mA) 0.25 0.25 No No
Substitute Leakage (mA) No No No No
Load/Leakage (VA/mA) 3000/0.25 No No 3000/0.25
Note: Test numbers 137 to 142 and 235 to 240 are reserved for future factory programmed tests.
