71X Series
Calibration Manual
6
Specifications
Specifications for the 71X Calibrators are based on a one-year calibration cycle and apply
for ambient temperatures from + 18 °C to + 28 °C unless stated otherwise. “Counts” are
the number of increments or decrements of the least significant digit. General
specifications for all models are in Table 2.
Table 2. General Specifications
Maximum voltage applied between any terminal
and earth ground or between any two terminals:
30 V
Storage temperature: 712: -20 °C to 60 °C, 718Ex: -40 °C to 71 °C, 719: -30 °C to 60 °C
All other models: -40 °C to 60 °C
(718Ex) Pressure Sensor Media: Non-corrosive gasses only
Operating temperature: -10 °C to 55 °C
Operating altitude: 3000 meters maximum
Relative humidity: 95 % up to 30 °C
75 % up to 40 °C
45 % up to 50 °C
35 % up to 55 °C
Vibration: Random 2 g, 5 Hz to 500 Hz
Shock: 1 meter drop test
Safety: 712, 714, 715, 717
Safety: 718
Safety: 718Ex
719
Certified as compliant to CAN/CSA C22.2 No. 1010.1:1992 NRTL
Complies with ANSI/ISA S82.01-1994
Certified as compliant to CAN/CSA C22.2 No. 1010.2:1995
Complies with ANSI/ISA S82.01-1995
Certified as compliant to CAN/CSA C22.2 No. 1010.2:1995
Complies with ANSI/ISA S82.01-1995. Complies with IEC 61010-1-
95 CAT I, 30 V;
• P ( II 1 G Ex ia IIC T4
0344 KEMA 04ATEX1061 X
•
) Class I Div. 1 Groups A-D T4
LR110460 AEx ia IIC T4
• Ta = -10 °C… +55 °C
• CE: Complies with EN61010-1 and EN61326
Complies with EN/IEC 61010-1 2
nd
ed.,
CSA-C22.0 No. 61010-1-04
Power requirements: 712, 714, 715, 717 Single 9 V battery (ANSI/NEDA 1604A or IEC 6LR61)
Power requirements: 718 Two 9 V batteries (ANSI/NEDA 1604A or IEC 6LR61)
Power requirements: 718Ex See “718Ex Approved Batteries”.
Size: 712, 714, 715, 717
Size: 718, 718Ex, 719
34.9 mm H x 87 mm W x 187 mm L;
With holster and Flex-Stand:
52 mm H x 98 mm W x 201 mm L
60 mm H x 87 mm W x 210 mm L;
With holster: 66 mm H x 94 mm W x 216 mm L
Weight:
712
714
715
717 30G, 717 100G
718 30G and 718 100G and
718Ex 30G and 718Ex 100G
719
337 g; With holster and Flex-Stand: 587 g
332 g; With holster and Flex-Stand: 584 g
349 g; With holster and Flex-Stand: 601 g
369 g; With holster and Flex-Stand: 624 g
737 g; With holster: 992G
912 g; With holster
