Process Calibrators
Verification
37
DC Voltage Measure Verification
1. Push the key on the 715 Calibrator. Display should change to:
INPUT 0.000 V
2. Connect test leads from the output NORMAL jacks of the Fluke 5520A to the voltage
jacks on the 715 Calibrator (black to COM jack and red to the V jack).
3. Set the Fluke 5520A for the voltage settings in Table 54, and verify the display
readings on the 715 Calibrator.
Table 54. 715 DC Voltage Measure Verification (10.0000 to 0.0000 V)
Fluke 5520A Fluke 715
10.00000 V 9.996 V to 10.004 V
5.00000 V 4.997 V to 5.003 V
0.0000 V -0.002 V to +0.002 V
4. Push the key on the 715 Calibrator. Display should indicate closely to:
INPUT 0.00 mV
5. Set the Fluke 5520A for the mV settings in Table 55, and verify display readings on
the 715 Calibrator.
Table 55. 715 DC Voltage Measure Verification (0.0000 mV to 100.0000 mV)
Fluke 5520A Fluke 715
0.0000 mV -0.02 mV to + 0.02 mV
50.0000 mV 49.97 mV to 50.03 mV
100.0000 mV 99.96 mV to 100.04 mV
6. Disconnect the test leads from 715 Calibrator and turn the green key off.
Display Verification
1. Push and hold the key and then turn the 715 back on by pressing and releasing
the green key. This locks the 715 in a mode where all display segments are on. All
segments will stay on until the key is released.
2. Check to see that all segments of the LCD are displayed.
3. Turn the 715 off.
The 715 verification test is complete.
