71X Series
Calibration Manual
50
Note
When verifying vacuum pressure make sure the pressure/vacuum switch is
in the vacuum position. Forward (clockwise) is for pressure and backward
(counter-clockwise) is for vacuum.
Table 64. 718 and 718Ex Pressure Verification
718 Version 3.9 or Below
718Ex V1.9 and Below
718 1G 718 and 718Ex 30G
Input
Pressure
Display
Reading
Input
Pressure
Display
Reading
0 PSI 0.0005 to -0.0005 0 PSI -0.015 to 0.015
0.1 PSI 0.1005 to 0.0995 6 PSI 5.985 to 6.015
0.2 PSI 0.2005 to 0.1995 12 PSI 11.985 to 12.015
0.3 PSI 0.3005 to 0.2995 18 PSI 17.985 to 18.015
0.4 PSI 0.4005 to 0.3995 24 PSI 23.985 to 24.015
0.5 PSI 0.5005 to 0.4995 30 PSI 29.985 to 30.015
0.6 PSI 0.6005 to 0.5995 24 PSI 23.985 to 24.015
0.7 PSI 0.7005 to 0.6995 18 PSI 17.985 to 18.015
0.8 PSI 0.8005 to 0.7995 12 PSI 11.985 to 12.015
0.9 PSI 0.9005 to 0.8995 6 PSI 5.985 to 6.015
1 PSI 1.0005 to 0.9995 -12 PSI * -12.015 to -11.985
-0.2 PSI -0.1995 to -0.2005
-0.4 PSI -0.3.995 to -0.4005
-0.6 PSI -0.5995 to -0.6005
-0.8 PSI -0.7995 to -0.8005
-1 PSI -0.9995 to -1.0005
718 Version 3.9 or Below
718Ex Version 1.9 or Below
718 and 718Ex 100G 718 and 718Ex 300G
Input
Pressure
Display
Reading
Input
Pressure
Display
Reading
0 PSI -0.05 to 0.05 0 PSI 0.15 to -0.15
20 PSI 19.95 to 20.05 60 PSI 60.15 to 59.85
40 PSI 39.95 to 40.05 120 PSI 120.15 to 119.85
60 PSI 59.95 to 60.05 180 PSI 180.15 to 179.85
80 PSI 79.95 to 80.05 240 PSI 240.15 to 239.85
100 PSI 99.95 to 100.05 300 PSI 300.15 to 299.85
80 PSI 79.95 to 80.05 240 PSI 240.15 to 239.85
60 PSI 59.95 to 60.05 180 PSI 180.15 to 179.85
40 PSI 39.95 to 40.05 120 PSI 120.15 to 119.85
20 PSI 19.95 to 20.05 60 PSI 60.15 to 59.85
* -12 PSI -12.05 to -11.95 -12 PSI -11.85 to -12.15
*Vacuum is only specified for V1.3 and later. To display the firmware version, start with the 717 off, push and
hold , then push the power button.
