Model 787
Calibration Manual
30
Using the
MET/CAL Calibration Software
To calibrate the UUT using the MET/CAL Calibration Software, start MET/CAL and
follow the prompts.
For each function being calibrated, you will be prompted to set the UUT rotary
switch to the correct position, and to make the appropriate connections between
the calibrator, other required equipment, and the UUT.
Except for positioning the rotary switch and making the proper connections, the
calibration process is completely automated.
XWarning
The
MET/CAL Calibration Software
program automatically puts the
Calibrator in Standby (STBY) mode before prompting you to change
connections.
To ensure your safety, however, always check the Calibrator to make
sure that it actually is in the Standby (STBY) before changing
connections with the UUT and all other equipment used in calibration.
Replaceable Parts
When servicing this ProcessMeter, use only the replacement parts specified. User-
replaceable parts are listed in Table 12 and shown in Figure 14.
Table 12. Replacement Parts
Item Description Fluke No. Quantity
BT1 9V battery, ANSI/NEDA 1604A or IEC 6LR61 614487 1
CG81Y Holster, Yellow CG81G 1
WF1, 2 Fuse, 440 mA, 1000 V fast-blow 943121 2
MP85 Case top 619962 1
MP86 Case bottom 619939 1
H2, 3, 4 Case screw 832246 3
MP89, 90 Non-skid foot 824466 2
MP8 O-ring for input/output receptacle 831933 1
MP92 Battery door 619947 1
H5, 6 Battery door fasteners 948609 2
S1 Keypad 646932 1
TL75 Standard test lead set TL75 1
AC70A Alligator clips for use with TL75 test lead set AC70A 1
TL20 Industrial test lead set TL20 Option
TM1 Product Overview Manual 1586717 1
TM2 Users Manual (CD-ROM) 1586721 1
TM3 Calibration Manual (not shown) 641891 Option
