Menu value Function Result
20 Analogue input Shows the raw input values (0-16383).
24 P1 current input Shows the raw input values (0-16383). This starts P1.
25 P2 current input Shows the raw input values (0-16383). This starts P2.
View status of digital inputs
View the Status inputs menu (17_2):
• 0 = passive
• 1 = active
Invert inputs
For an input in the Invert inputs menu (17_3), select:
• "1" to invert the input.
• "0" for no inversion. (Default state).
Run a diagnostic program
Select the program in the Diagnostic program menu (17_8).
Reset RTU to default settings
1. Select "Yes" in the Flygt default menu (17_9).
Result: RTU restarts, and the text "Restart" is shown in the display.
2. Wait until the restart is complete, and the text have disappeared.
Miscellaneous
