Alarm
Code
Default
priority
Local text SCADA System Text Description
8510 B High capacity
P1
High capacity P1 The RTU has calculated a capacity higher than the high capacity alarm
level for pump 1.
8511 B High capacity
P2
High capacity P2 The RTU has calculated a capacity higher than the high capacity alarm
level for pump 2.
8512 B High capacity
P3
High capacity P3 The RTU has calculated a capacity higher than the high capacity alarm
level for pump 3.
8513 B High capacity
P4
High capacity P4 The RTU has calculated a capacity higher than the high capacity alarm
level for pump 4.
8514 B Low capacity P1 Low capacity P1 The RTU has calculated a capacity lower than the low capacity alarm level
for pump 1.
8515 B Low capacity P2 Low capacity P2 The RTU has calculated a capacity lower than the low capacity alarm level
for pump 2.
8516 B Low capacity P3 Low capacity P3 The RTU has calculated a capacity lower than the low capacity alarm level
for pump 3.
8517 B Low capacity P4 Low capacity P4 The RTU has calculated a capacity lower than the low capacity alarm level
for pump 4.
8538 B I/O-mod not
resp
I/O-module(s) not
responding
Communication problem with I/O-module. The I/O-module is not
responding.
8539 C Wrong I/O-
module
Wrong type of I/O-
module
Communication problems with I/O units. Wrong unit type.
8602 B High level
+pfail
High level
+pumpfailure
The level is high and in the same time there is a failure on at least one
pump
8606 B P1 switched off P1 switched off Pump 1 is switched off. i.e. not in auto mode
8607 B P2 switched off P2 switched off Pump 2 is switched off. i.e. not in auto mode
8608 B P3 switched off P3 switched off Pump 3 is switched off. i.e. not in auto mode
8609 B P4 switched off P4 switched off Pump 4 is switched off. i.e. not in auto mode
8615 B Failure 2
pumps
Failure on two pumps There are failures on 2 or more pumps
8630 B Testcall ! Testcall ! A test alarm is sent in order to verify that the RTU and its communication
are working properly. The alarm is sent at a regular interval, which is
configurable.
8652 C High rain 5
min
High rainfall 5 min The RTU has calculated a rainfall higher than the rain alarm limit for 5
minutes.
8653 C High rain 24 h High rainfall 24 h The RTU has calculated a rainfall higher than the rain alarm limit for 24
hours.
List of Menus
No.
Menu name Specification Description
1 Alarm log Writable Alarm log.
2 Level ft Read only Level indication.
Appendix A: RTU Descriptions
APP 541 User manual 47
