Text1 Text2 Text3 Description
Run time P4 h:min Running time pump 4.
Overflow time h:min Overflow time.
Starts P1 Number of starts pump 1.
... ...
Starts P4 Number of starts pump 4.
Rain inch Rain.
Overflow count Number of overflows.
Major overflow count Major overflow count
Overflow volume gal Overflow volume
Pumped volume gal Pumped volume
Trend
The trend data consist of historical data with selectable sample resolution (1 or 5 minute
average).
Available data is listed in the table below. The RTU stores this data for 4 days.
Text1
Text2 Text3 Description
Level ft Level
Current P1 A P1 current. (Maximum value in period).
... ...
Current P4 a P4 current. (Maximum value in period).
Rain P1 inch Rain. 5 minute running average.
Calculated cap. P1 GPM Calculated capacity P1
... ...
Calculated cap. P4 GPM Calculated capacity P4
Overflow Level ft Overflow level
Overflow Height ft Overflow height
Free flow l/s Free flow (inflow)
To set trend resolution in the RTU:
• Enter the preferred resolution in the Trend resolution menu (16_4).
• Keep in mind: Use the same trend resolution in the RTU as in AquaView.
Other SCADA Systems
The figure on next page shows a status view example using Citect.
Communication Methods
The RTU supports several communication methods for communicating with other SCADA
systems:
