No. Menu name Specification Description
8_9 Overflow segment 4
GPM
WritableCentral System
TextOverflow segment 4 (GPM)
Overflow segment 4 used by the manual calculation method to
calculate overflow flow and overflow volume.
8_10 Overflow segment 5
GPM
WritableCentral System
TextOverflow segment 5 (GPM)
Overflow segment 5 used by the manual calculation method to
calculate overflow flow and overflow volume.
8_11 Overflow segment 6
GPM
WritableCentral System
TextOverflow segment 6 (GPM)
Overflow segment 6 used by the manual calculation method to
calculate overflow flow and overflow volume.
8_12 Overflow segment 7
GPM
WritableCentral System
TextOverflow segment 7 (GPM)
Overflow segment 7 used by the manual calculation method to
calculate overflow flow and overflow volume.
8_13 Overflow segment 8
GPM
WritableCentral System
TextOverflow segment 8 (GPM)
Overflow segment 8 used by the manual calculation method to
calculate overflow flow and overflow volume.
8_14 Overflow segment 9
GPM
WritableCentral System
TextOverflow segment 9 (GPM)
Overflow segment 9 used by the manual calculation method to
calculate overflow flow and overflow volume.
8_15 Overflow segment 10
GPM
WritableCentral System
TextOverflow segment 10 (GPM)
Overflow segment 10 used by the manual calculation method to
calculate overflow flow and overflow volume.
8_16 Overflow flow GPM Read only Overflow flow
8_17 Overflow volume gal Read only Overflow volume
8_18 Overflow count Writable Number of overflows.
8_19 No. of major overfl. Writable No. of major overfl.
8_20 Overflow time h:min Writable Overflow time.
9 Rain inch Writable Rain daily value.
9_1 Rain alarm 5min
inch/5min
Writable Rain limit for 5 minute period.
9_2 Rain alarm 24h
inch/24h
Writable Rain alarm limit for 24 hours.
9_3 Rain scale inch/pulse Writable Rain meter scale factor.
10 Flows and volumes Read only Flows and volumes
10_1 Free flowGPM Read only Free flow
10_2 Pumped volume gal Read only Pumped volume
10_3 Sump volume gal Read only Sump volume
11 Sump form Read only Sump form
11_1 Area ft2 WritableCentral System TextArea
(ft2)
This is the area that is used in the capacity calculations.
12 Capacity Read only Capacity
12_1 Calc. capacity P1GPM Read only Calc. capacity P1
12_1_1 Nominal capacity
P1GPM
WritableCentral System
TextNominal capacity P1 (GPM)
Enter the nominal capacity of P1. Used for capacity alarms.
12_1_2 Capacity div. P1GPM WritableCentral System
TextCapacity divergation limit P1
(GPM)
Divergation limit for high and low capacity alarms. Uses nominal
capacity +/- this channel.
Appendix A: RTU Descriptions
50 APP 541 User manual
