Table 1 - Battery Element description
Symbol Description
•Battery level above 90%
•Battery level between 70% and 89%
•Battery level between 50% and 69%
•Battery level between 30% and 49%
•Battery level between 15% and 29%
•Less than 15% battery remaining
5.1.2 Sound
The Sound Element provides graphical representation on the current volume level. Table 2
Shows the relationship between what is shown and the sound level. This element has
fixed dimensions.
Table 2 - Sound Element description
Symbol Description
•Sound Level 6 (maximum sound level)
•Sound Level 5
•Sound Level 4
•Sound Level 3
•Sound Level 2
•Sound Level 1
•Sound is muted (No sound)
Document version: 2.0 Page 11
