FMC Technologies Smith Meter AccuLoad II Programming Workbook

Program Program
Code Function Code Description Entry Code
6 AB06030 Rev. 0.6 5/96
013 A/C Input 4 Enter: "00" No Assignment (NAS) 013
Terminals 103 & 105 "01" Additive Feedback 1 (AFB1)
(Position #1) "02" Additive Feedback 2 (AFB2)
Terminals 110 & 112 "03" Additive Feedback 3 (AFB3)
(Position #2) "04" Additive Feedback 4 (AFB4)
"05" Additive Feedback 5 (AFB5)
"06" Additive Feedback 6 (AFB6)
"07" Additive Feedback 7 (AFB7)
"08" Block Valve Feedback 1 (BVF1)
"09" Block Valve Feedback 2 (BVF2)
"10" Block Valve Feedback 3 (BVF3)
"11" Block Valve Feedback 4 (BVF4)
"12" First/Second High Flow (FSC)
"13" Printer Tray Switch (PTS) *
"14" Permissive 1 Contact (PRC1)
"15" Permissive 2 Contact (PRC2)
"16" Valve Power (VPS)
"17" Valve Stem (VST) __ __
Note: 1. Or can be used for Master Reset.*
2. For "Remote Start" operation this code must be programmed "14" (Permissive Contact #1), code 806 must be programmed "5"
(Remote Start) and jumpers must be installed as shown in the Installation Manual (MN06037).
3. When using a Smart Additive Subsystem, options 01 through 07 (Additive Feedbacks) are not available for selection.
014 A/C Input 5 Enter: "00" No Assignment (NAS) 014
Terminals 104 & 105 "01" Additive Feedback 1 (AFB1)
(Position #1) "02" Additive Feedback 2 (AFB2)
Terminals 111 & 112 "03" Additive Feedback 3 (AFB3)
(Position #2) "04" Additive Feedback 4 (AFB4)
"05" Additive Feedback 5 (AFB5)
"06" Additive Feedback 6 (AFB6)
"07" Additive Feedback 7 (AFB7)
"08" Block Valve Feedback 1 (BVF1)
"09" Block Valve Feedback 2 (BVF2)
"10" Block Valve Feedback 3 (BVF3)
"11" Block Valve Feedback 4 (BVF4)
"12" First/Second High Flow (FSC)
"13" Printer Tray Switch (PTS) *
"14" Permissive 1 Contact (PRC1)
"15" Permissive 2 Contact (PRC2)
"16" Valve Power (VPS)
"17" Valve Stem (VST) __ __
Note: 1. Or can be used for Master Reset.*
2. For "Remote Stop" operation this code must be programmed "15" (Permissive 2 Contact), code 810 must be programmed "5"
(Remote Stop) and jumpers must be installed as shown in the Installation Manual (MN06037).
3. When using a Smart Additive Subsystem, options 01 through 07 (Additive Feedbacks) are not available for selection.
