907-0601-00 Rev. C Model 907 Video/Data Multiplexer – User’s Guide
Focal Technologies Corp. Page 3-5
Figure 3-5 shows a 907V multiplexer motherboard and Figure 3-6 shows the I/O channels for the 907V-R and
907V-C multiplexer motherboard cards.
Figure 3-5: Model 907V Multiplexer Motherboard
OPTICAL CABLE SYSTEM
VIDEO INCH6
VIDEO INCH5
VIDEO INCH4
REMOTE
(907V-R)
VIDEO INCH3
VIDEO INCH2
VIDEO INCH1 VIDEO OUT CH6
VIDEO OUT CH5
VIDEO OUT CH4
CONSOLE
(907V-C)
VIDEO OUT CH3
VIDEO OUT CH2
VIDEO OUT CH1
Figure 3-6: On board I/O Channels for 907V-R and 907V-C Multiplexer Motherboard Cards
