Focal 907 - Appendices; Appendix A - Fuses

907-0601-00 Rev. C Model 907 Video/Data Multiplexer – User’s Guide
Focal Technologies Corp.
Appendices
Appendix A – Fuses
Card Type
Card
Qty.
Fuse P/N
Current
Rating
Comments
907
Multiplexer
Motherboards
907
1
0452002
2.0 A
Replaceable SMT fuse for +5 VDC from power connector (F1)
907+
1
0452002
2.0 A
Soldered SMT fuse for +5 VDC from power connector (F1)
907V
1
0452002
2.0 A
Soldered SMT fuse for +5 VDC from power connector (F1)
907-HDM2
1
0452002
2.0 A
Soldered SMT fuse for +5 VDC from power connector (F1)
907-GEM
1
0452003
3.0 A
Soldered SMT fuse for +5 VDC from power connector (F1)
907
Media
Converters
907-MC
1
0452001
1.0 A
Soldered SMT fuse for +5 VDC from power connector (F1)
907-1394
1
0452001
1.0 A
Soldered SMT fuse for +5 VDC Board Voltage (F5)
0452003
3.0 A
Soldered SMT fuse for +5 VDC from power connector (F1)
907-ECL
2
0452001
1.0 A
Soldered SMT fuse for +5 VDC (F1-backplane, F2- power
header)
907-HDV
2
0452001
1.0 A
Soldered SMT fuse for +5 VDC (F1-backplane, F2- power
header)
907-GBE
1
0452001
1.0 A
Soldered SMT fuse for +5 VDC from power connector (F1)
907-GBE2
1
0452003
3.0 A
Soldered SMT fuse for +5 VDC feed to backplane (F1)
0452005
5.0 A
Soldered SMT fuse for +5 VDC from power connector (F2)
907-GBES
1
0452005
5.0 A
Soldered SMT fuse for +5 VDC feed to backplane (F2)
0452005
5.0 A
Soldered SMT fuse for +5 VDC from power connector (F1)
907
Expansion
Cards
907-EIBS
1
0452002
2.0 A
Soldered SMT fuse for +5 VDC from backplane (F1)
907-232
1
0452002
2.0 A
Soldered SMT fuse for +5 VDC from backplane (F1)
907-485
1
0452002
2.0 A
Soldered SMT fuse for +5 VDC from backplane (F1)
907-SER
1
0452002
2.0 A
Soldered SMT fuse for +5 VDC from power connector (F1)
907-ADC
1
0452002
2.0 A
Soldered SMT fuse for +5 VDC from backplane (F1)
907-DAC
1
0452002
2.0 A
Soldered SMT fuse for +5 VDC from backplane (F1)
907-AUDIO
1
0452005
5.0 A
Spare fuse in holder for +5 VDC from backplane (F1)
907-TLL
1
0452002
2.0 A
Soldered SMT fuse for +5 VDC from backplane (F1)
907-CIB
1
0452002
2.0 A
Soldered SMT fuse for +5 VDC from backplane (F1)
907-420
1
0452002
2.0 A
Soldered SMT fuse for +5 VDC from backplane (F1)
907-USB
1
0452002
2.0 A
Soldered SMT fuse for +5 VDC from power connector (F1)
907-AIB
1
0452001
1.0 A
Soldered SMT fuse for +5 VDC (F1)
907
System
Modules
907-EURO
1
0452003
3.0 A
Soldered SMT fuse for +5 VDC from backplane (F1)
907-DC-24
1
0452003
3.0 A
Soldered SMT fuse for +24 VDC (F1)
907-FOS
1
0452001
1.0 A
Soldered SMT fuse for +5 VDC from backplane (F1)
907-DIAG
1
0452002
2.0 A
Soldered SMT fuse for +5 VDC from backplane (F1)
907-DIAG-E
1
0452002
2.0 A
Soldered SMT fuse for +5 VDC from backplane or USB (F1)
NOTES:
1. SMT = Surface Mount Technology
2. 0452 type devices are time delay fuses manufactured by Littelfuse.
