3.4.2 Console 907-HDM2 Multiplexer Card (907-HDM2-C)
The card views for the 907-HDM2-C multiplexer motherboard are identical to the 907-HDM2-R shown in
Figure 3-16. The console card electrical and optical interfaces are all identical to the remote except that the
two SMB video connectors are used instead of the two inputs. Output impedance for each video connector is
75 ohms.
At the 907-HDM2-C (console end), the HD-SDI monitor or processing equipment is attached to 75-ohm
Mini-SMB jacks J9/J11, as shown in Figure 3-16. Note that mating connectors and cables must be 75-ohm
impedance.
A 907-DIAG-E diagnostic card may be stacked with the 907-HDM2-C to obtain critical system diagnostics of
both the remote and console stacks through an Ethernet interface. More details of the 907-DIAG-E card are
provided in the System Modules section.
