Focal 907 - Appendix C - Model 907 Power Current; Rev. C

907-0601-00 Rev. C Model 907 Video/Data Multiplexer – User’s Guide
Focal Technologies Corp.
Appendix C – Model 907 Power Current
POWER
VOLTAGE
(V)
TYP MIN TYP MAX MIN TYP MAX
907
Standard 907 Multiplexer
Motherboard
907-0001-02 907-2001-00 5 - 0.70 1.00 - 3.50 5.00
907V
907V Multiplexer
Motherboard - Remote
907-0023-00 907-2026-00 5
- 0.70 1.00 - 3.50 5.00
907V
907V Multiplexer
Motherboard - Console
907-0024-00 907-2026-00 5
- 0.70 1.00 - 3.50 5.00
907+
907Plus Remote Multiplexer
Motherboard
907-0025-00
907-2035-00 5 - 0.70 1.00 - 3.50 5.00
907+
907Plus Console Multiplexer
Motherboard
907-0026-00
907-2036-00 5 - 0.70 1.00 - 3.50 5.00
907-HDM2
907-HDM2 Multiplexer
Motherboard
907-0050-13
907-2052-00 5 - 1.30 2.00 - 6.50 10.00
907-GEM
907-GEM Gigabit Ethernet
Multiplexer Motherboard
907-0060-13
907-2056-00 5 0.50 1.30 1.60 2.50 6.50 8.00
907-MC
10/100 Mbps Ethernet 907-0014-47 907-2007-00 5 - 0.35 0.70 - 1.75 3.50
907-MC
10/100 Mbps Ethernet 907-0014-00 907-2007-01 5 - 0.35 0.70 - 1.75 3.50
907-MC
10/100 Mbps Ethernet 907-0014-13 907-2007-02 5 - 0.35 0.70 - 1.75 3.50
907-ECL
Sonar 907-0019-17 907-2012-02 5 - 0.50 0.70 - 2.50 3.50
907-HDV
HD-SDI 907-0022-00 907-2012-00 5 - 0.50 0.70 - 2.50 3.50
907-GBE
Gigabit Ethernet 907-0021-00 907-2023-00 5 - 0.80 1.60 - 4.00 8.00
907-GBE2
Dual Gigabit Ethernet 907-0030-00 907-2040-00 5 0.30 1.00 1.50 1.50 5.00 7.50
907-GBES
Quad Gigabit Ethernet
Switch
907-0027-00 907-2037-00 5 - 1.00 2.00 - 5.00 10.00
907-EIBS
10 Mbps Ethernet Switch
Card
907-0222-00 907-2019-00 5
- 0.40 0.80 - 2.00 4.00
907-232
8-Channel RS-232 Card 907-0212-00 907-2008-00 5 - - 0.80 - - 4.00
907-485
8-Channel RS-422/485 Card 907-0217-00 907-2015-00 5 0.50 - 1.00 2.50 - 5.00
907-SER
8-Channel RS-232/
RS-422/RS-485 Card
907-0242-00 907-2047-00 5
0.42 0.75 1.50 2.10 3.75 7.50
907-ADC
8-Channel 8/12 bit ADC Card 907-0218-00 907-2016-00 5 0.10 0.20 0.40 0.50 1.00 2.00
907-DAC
8-Channel DAC Card 907-0219-00 907-2017-00 5 - 0.20 0.50 - 1.00 2.50
907-AUDIO
4-Channel, 24-bit Audio Card 907-0228-00 907-2030-00 5 - 0.30 3.00 - 1.50 15.00
907-TTL
8-Channel TTL Card 907-0212-01 907-2008-01 5 - - 0.80 - - 4.00
907-CIB
4-Channel Control Interface
Card
907-0231-00 907-2027-00 5
- 0.32 0.40 - 1.60 2.00
907-420
6-Channel 4-20 mA Card 907-0218-01 907-2024-00 5 0.12 0.20 0.40 0.60 1.00 2.00
907-USB
Universal Serial Bus Card 907-0224-24 907-2022-00 5 - 0.20 0.60 - 1.00 3.00
907-AIB
Dual-Socket AIB Adaptor 907-0204-00 907-2004-00 5 0.03 0.10 0.15 - 0.50
907-EURO
Eurocard Adaptor 907-0221-00 907-2018-00 5 - 0.03 0.10 - 0.15 0.50
907-DC-24
Isolated DC-DC Power Card 907-0233-00 907-2029-00 24 0.10 - 0.22 2.40 - 5.28
907-FOS
1x2 SMF/MMF Fiber Optic
Switch Card
907-0015-XX 907-2031-00 5
0.02 0.07 0.09 0.12 0.35 0.45
907-DIAG
Diagnostics Card, LED Driver 907-0234-XX 907-2033-XX 5 0.07 - 0.30 0.35 - 1.50
907-DIAG-E
Diagnostics Card, Ethernet 907-0238-00 907-2039-00 5 - 0.30 0.50 - 1.50 2.50
POWER CONSUMPTION (WATTS)
CARD
TYPE
CARD ID
DESCRIPTION
CONFIG.
DWG.
CARD P/N
907 Multiplexer Motherboards
907 Media Converters
907 Expansion Cards
907 System Modules
POWER CURRENT (AMPS)
All measurements at T
A
= +25 °C
