907-0601-00 Rev. C Model 907 Video/Data Multiplexer – User’s Guide
Focal Technologies Corp. Page 5-6
When the card part number used is 907-0242-00, switch SW3 and SW4 are used to configure each channel
individually as either RS-232 or RS-485. When the card part number used is 907-0242-01, switch SW3 and
SW4 must be set in the ON position (default).
Additionally, a 907-SER pair (remote and console) can be used to convert from RS-232 to RS-485/422 and
vice versa. Cable assembly rewiring may be required depending on the card configuration. Please contact
Focal for more details about this feature.
