Follett L78614 - Fan Removal

Fan removal
1. Remove 4 fan mounting screws and 3 drain
tubes from bracket.
Fig. 24
REMOVE DRAIN TUBES
FROM DRAIN CAP.
REMOVE DRAIN CUP
AND CAP.
REMOVE FAN BASE
MOUNTING SCREWS.
2. Rotate fan mounting bracket toward back of unit
and pull fan assembly toward front of unit.
Fig. 25
ROTATE BASE OF FAN
TOWARDS BACK OF UNIT.
MOVE FAN AWAY FROM
CONDENSER.
MOVE FAN TOWARDS
FRONT OF UNIT TO
COMPLETE REMOVAL.
40 12CI425A, 12HI425A
