Follett L78614 - Dispense Chute and Splash Panel (Models with Lever Dispensing)

Dispense chute and splash panel (models with lever dispensing)
1
7
6
7
6
5
4
4
10
3
3
9
5
8
9
1
2
Reference # Description Part #
1 Chute, ice or water (with Agion
®
antimicrobial product protection
1
) 00967760
2 Support, water tube 00960682
3 Lever 00976845
4 Boot, dispense switch button 502418
5 Screw, panel 00982421
6 Switch, dispense 00981217
7 Bracket, lever support 00958793
8 Tube, water solenoid 502420
9 Fitting, bulkhead (with nut) 00976787
Not shown Splash panel (ice only) 01161256
10 Splash panel 00969980
1
Disclaimer: Antimicrobial protection is limited to the treated components and does not treat water or ice.
Agion is a registered trademark of Sciessent LLC.
44 12CI425A, 12HI425A
