Ford 2002 Think - Weather Enclosure System

TRUNK EXPANDER (IF EQUIPPED)
The trunk
expander is a
locking storage
area that is
inserted into
the trunk to
increase the
amount of
storage. The
trunk expander
is designed to
hold two paper
grocery bags in
the bottom with
three plastic
bags hung from
hooks mounted
inside the trunk
expander. There
are two shelves
to the right and
left of the main
area to hold other items.
The hooks should not be loaded with over 8 lbs
(3.6 kg).
The trunk should not be loaded to over 200 lbs
(90.7 kg).
WEATHER ENCLOSURES (IF EQUIPPED)
The weather enclosures are designed to be installed
on the vehicle to help shield the vehicle users and
the interior of the vehicle from inclement weather.
To install the weather enclosure:
Side panels:
Note: Opening the front access panel zipper can help
install the side panels.
1. Insert the side weather enclosure front hanger
(“T” section) into the slot on the underside of the
roof rail in front of the safety belt hanger bracket.
