LUGGAGE ANCHOR POINTS

E167350

Maximum Load

Value

Variant

785 lb (357 kg)Transit Courier

900 lb (408 kg)Transit Connect

REAR UNDER FLOOR

STORAGE

Passenger Compartment Floor (If

Equipped)

E78097

The under floor storage compartment is

located behind the front passenger seat.

Adjustable Load Floor (If Equipped)

E142446

148
