FUSE SPECIFICATION CHART

Engine Compartment Fuse Box

E157389

Circuits protectedFuse ratingFuse

Not used.-F1

Not used.-F2

Not used.-F3

Not used.-F4

Not used.-F5

Not used.-F6

Anti-lock brake system.

40A

**

F7

Stability control.

30A

**

F8

182

Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, First Printing

Fuses
