PROTECTING THE

ENVIRONMENT

You must play your part in protecting the

environment. Correct vehicle usage and

the authorized disposal of waste, cleaning

and lubrication materials are significant

steps toward this aim.

Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, First Printing

Environment
