Passenger Compartment Fuse Box

E129926

Circuits protectedFuse ratingFuse

Fuel pump.20AF56

Not used.-F57

Not used.-F58

Passive anti-theft system transceiver.5AF59

Interior lamp.10AF60

Driver door switch pack.

186

Tourneo Connect/Transit Connect (CHC) Canada/United States of America, enUSA, First Printing

Fuses
