When switched off in the information

display, the daytime running lamps are off

in all lighting control switch positions.

FRONT FOG LAMPS

E142453

Press the button to switch the fog lamps

on or off.

You can switch the fog lamps on when the

lighting control is in any position except off

and the high beams are not turned on.

CORNERING LAMPS

E72898
