27
Vacuum
This operation will latch the pump and the vacuum valve ON to apply vacuum to the table
hole.
Release
This operation will apply compressed air to the table hole. This function does not latch but
will unlatch the vacuum. Press & hold to run.
Pre-Stretch
This operation will turn on the compressed air valve to allow air to flow into the sealed
cabinet. This function does not latch. Press & hold to run. 508FS only.
Auto-level
This operation enables a sensor to provide automatic levelling of the sheet level during
heating. Compressed air is applied under the heated sheet when the beam is broken. This
button latches and may be enabled / disabled at any time. 508FS only.
Fan Timer
This operation will latch the fan on for the time set for loaded settings. The fans will turn off
when the time has elapsed. 508FS only.
Introduction to the 508 control system - Operating buttons and icons (continuation)
Operating Procedures - Quick start guide
