Manual - Formech 508DT/FS - Rev 3
3
Table Of Content
Optional extras 36
Tools 37
508DT/FS standard baseboard 38
508DT/FS reducing window baseboard 39
Plastics 40
Post Forming Operations 41
After forming 41
Trimming 41
Warranty 42
Seals 42
Heating elements 42
Vacuum system 42
Service / Repair 43
Replacing seals 43
Replacing a heating element 44
Electrical Troubleshooting 46
Vacuum / Pressure Troubleshooting (508DT & 508FS) 48
Cleaning 49
Lubrication 49
Electrical Wiring - 508DT 50
Vacuum Pump 2D351VM - 508DT only 51
Electrical Wiring - 508FS 53
Becker Pump VT 4.10 - 508FS Only 54
Pneumatics 508DT & 508FS 56
Major Parts Listing 508DT & 508FS 57
EC Certificate 59
