Introduction | 7
Minimum dimensions for
convenient access (W × D × H)
40.7 × 47.8 × 84.4 cm | 16.0 × 18.8 × 33.2 in
Printer dimensions (W × D × H) 39.8 × 36.7 × 55.4 cm | 15.7 × 14.5 × 21.9 in
Printer weight 18.3 kg | 40.4 lb
Build volume (W × D × H)
200 × 125 × 210 mm | 7.9
× 4.9 × 8.3 in
Parts taller than 190 mm (7.5 in) require that the resin tank be
removed with the build platform and the wash basket be removed
from Form Wash
Layer thickness (Axis resolution) 25–300 microns | 0.001–0.012 in
XY resolution 50 micron pixel size with pretuned anti-aliasing | 0.002 in
Optical power intensity 16 mW/cm
2
delivered to the print plane
Optical wavelength 405 nm
Resin cartridges 1
Resin dispensing system Automated
Biocompatible materials Ye s
Supports Auto-generated, Light-touch removal
Operating environment 18–28 °C | 64–82 °F
Low ambient humidity
Operating temperature Auto-heats resin to 25–45 °C (77–113 °F), depending on material
Temperature control Direct resin heating
Power requirements 100–240 VAC
Maximum 4.8 A
50/60 Hz
480 W
Connectivity Wi-Fi: 2.4, 5 GHz
Ethernet: 1000 Mbit
USB: 2.0
Wi-Fi connectivity Protocol: IEEE 802.11 b/g/n
Frequency: 2.4 GHz, 5 GHz
Supported security: WPA/WPA2
Ethernet connectivity RJ-45 Ethernet (10BASE-T/100BASE-TX/1000BASE-T) LAN Port
Connect with a shielded Ethernet cable (not included): minimum
Cat5, or Cat5e or Cat6 for 1000BASE-T.
USB connectivity USB C port with a USB C-A cable
Printer control Interactive touchscreen
Alerts Touchscreen alerts
SMS/email via Dashboard
Speaker for audio alerts
Camera Integrated camera
2592 × 1944 resolution (5 MP)
Print preparation PreForm desktop software
File type STL, OBJ, or 3MF
