Installing the FortiGate unit
This section provides information on installing and setting up the FortiGate unit on
your network. This section includes the following topics:
• Package Contents
• Air Flow
• Mechanical Loading
• Powering on the FortiGate unit
• Connecting to the FortiGate unit
Package Contents
Review the contents of your FortiGate package to ensure all components were
included.
FortiGate-200A
The FortiGate-200A package contains the following items:
• FortiGate-200A Unified Threat Management System
• one orange crossover Ethernet cable (CC300248)
• one gray straight-through Ethernet cable (CC300249)
• one RJ-45 to DB-9 serial cable (CC300302)
• two 19-inch rack mount brackets
• one power cable
• FortiGate-200A QuickStart Guide
• Fortinet Tools and Documentation CD
Figure 1: FortiGate-200A package contents
Esc Enter
DMZ2DMZ1INTERNAL WAN1 WAN2CONSOLE USB
1234
A
Power Cable
Rack-Mount Brackets
Ethernet Cables:
Orange - Crossover
Grey - Straight-through
Front
LCD
Control
Buttons
Internal
(4-port switch)
Power
LED
DMZ
1, 2
WAN
1, 2
Back
Power
Connection
Power
Switch
USB
(future)
Serial
Port
RJ-45 to
DB-9 Serial Cable
Documentation
USER MANUAL
FortiGate-200A
