FortiGate-200A, FortiGate-300A, FortiGate-400A, and FortiGate-500A FortiOS 3.0 MR4 Install Guide
16 01-30004-0268-20070712
Package Contents Installing the FortiGate unit
Mounting
The FortiGate-200A can be installed on any stable surface. The FortiGate-200A
unit can also be mounted on a standard 19-inch rack. It requires 1 U of vertical
space in the rack.
Table 1: Technical Specifications
FortiGate-300A
The FortiGate-300A package contains the following items:
• FortiGate-300A Unified Threat Management System
• one orange crossover Ethernet cable (CC300248)
• one gray straight-through Ethernet cable (CC300249)
• one RJ-45 to DB-9 serial cable (CC300302)
• two 19-inch rack mount brackets
• one power cable
• FortiGate-300A QuickStart Guide
• Fortinet Tools and Documentation CD
Figure 2: FortiGate-300A package contents
Dimensions 16.8 x 10 x 1.75 in. (42.7 x 25.4 x 4.5 cm.)
Weight 7.3 lb. (3.3 kg)
Power Requirements Power consumption: 14W
AC input voltage: 100 to 240VAC
AC input current: 1.6A
Frequency: 50 to 60Hz
Environmental
specifications
Operating temperature: 32 to 104 F (0 to 40 C)
Storage temperature: -13 to 158 F (-25 to 70 C)
Humidity: 5 to 95% non-condensing
Esc Enter
CONSOLE 10/100 10/100/1000USB
1 2 3 4 5 6
Power Cable
Rack-Mount Brackets
Ethernet Cables:
Orange - Crossover
Grey - Straight-through
Front
LCD
Control
Buttons
Power
LED
1, 2, 3, 4
10/100
5, 6
10/100/1000
RJ-45 to
DB-9 Serial Cable
Back
Power
Connection
Power
Switch
USB
(future)
Serial
Port
Documentation
USER MANUAL
FortiGate-300A
Copyright 2006 Fortinet Incorporated. All rights reserved.
Trademarks
Products mentioned in this document are trademarks.
QuickStart Guide
Esc Enter
DMZ2DMZ1INTERNAL WAN1 WA N2CONSOLE USB
1234
A
